Product Model
279-347
Selling Points
- 1Secure Connections: The CAGE CLAMP® connection technology ensures reliable connections without wire damage.
- 2Compact Design: Three phases and one ground conductor in a single terminal block for space-saving installations.
- 3Durable Construction: Built to withstand harsh environments, ideal for outdoor and industrial applications.
- 4Easy Testing: Compatible with test plugs for quick and efficient testing of connections.
- 5Universal Compatibility: Suitable for various electrical installations, including rail traffic, power generation, and more.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 72.2?mm?/ 2.843?inches |
Depth | 25.4?mm?/ 1?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.078MJ | Weight | 2.7g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332293303 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
