Product Model
280-494
Selling Points
- 1Quick and Easy Disconnection: The pull-tab feature allows for effortless handling, streamlining maintenance procedures.
- 2Reliable Connectivity: Durable construction ensures safe and efficient electrical connections, protecting sensitive systems.
- 3High Performance Standards: Optimizes operation and extends equipment lifespan in demanding environments.
- 4User-Friendly Design: Enhances overall system reliability with its user-friendly pull tab feature.
- 5Compliant with RoHS: Meets environmental product compliance standards, ensuring eco-friendliness in industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 16.7 mm / 0.657 inches | Height | 4 mm / 0.157 inches |
Depth | 30.6 mm / 1.205 inches | Jumper assignment | 1-2 |
Note (material data) | Information on material specifications can be found here | Color | orange |
Material group | I | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Fire load | 0.011MJ |
Weight | 1.2g | eCl@ss 10.0 | 27-14-11-40 |
eCl@ss 9.0 | 27-14-11-40 | ETIM 9.0 | EC000489 |
ETIM 8.0 | EC000489 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454062194 |
Customs tariff number | 8536698000 | RoHS Compliance Status | Compliant,No Exemption |
Rated current | 24A |
Specifications may be subject to change without notice
