Product Model
280-623/281-410
Selling Points
- 1Utilizes CAGE CLAMP technology for fast, vibration-proof, and maintenance-free connections.
- 2Requires cleaning and application of 'Alu-Plus' contact paste for secure aluminum conductor connections.
- 3Designed for mounting on DIN-rail 35 x 15 and 35 x 7.5, ensuring easy integration into various industrial settings.
- 4Rated for 0.5 A per IEC/EN 60947-7-1, making it suitable for a wide range of applications.
- 5Meets stringent safety standards including Det Norske Veritas, Germanischer Lloyd, DNV GL, and EN 60947 certifications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 4 | Total number of potentials | 1 |
Number of levels | 1 | Width | 5?mm?/ 0.197?inches |
Height | 73?mm?/ 2.874?inches | Depth from upper-edge of DIN-rail | 28?mm?/ 1.102?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Side marking | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.163MJ | Weight | 8.7g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-27 |
eCl@ss 9.0 | 27-14-11-27 | ETIM 9.0 | EC000903 |
ETIM 8.0 | EC000903 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4050821275411 |
Customs tariff number | 8536904000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 7(a) | SCIP notification number (Austria) | b3cf3e67-a4d3-4576-9bb9-9f8b7c8bdaa4 |
SCIP notification number (Belgium) | bb7ed019-8868-4060-9eb4-d4ca56073362 | SCIP notification number (Bulgaria) | db985997-13d6-4161-a03f-375ca24b2c89 |
SCIP notification number (Czech Republic) | bcd48c04-6893-4c48-9e0d-d533870bc668 | SCIP notification number (Denmark) | b14d073e-08e2-4e32-ab4c-555310a17bdc |
SCIP notification number (Finland) | 0fa0d9e6-56c3-4ed7-b9f6-bb4f56d4d6c8 | SCIP notification number (France) | 9360cb1c-4909-4001-93d1-0385be578066 |
SCIP notification number (Germany) | 026ede26-9f21-4338-9d41-843c645ee64d | SCIP notification number (Hungary) | d95bcdbd-3993-4c77-9e30-696f20d1fa82 |
SCIP notification number (Italy) | d275d92c-4c7f-42d5-97e6-72353e5640a9 | SCIP notification number (Netherlands) | 3e8ded6d-c4aa-4894-b7fd-b4cb6ce11a11 |
SCIP notification number (Poland) | c8581d7c-ee51-46ec-9efc-b17b14e03297 | SCIP notification number (Romania) | 4f93a0d7-dcb4-4030-8ac8-ac7f08f1d5fe |
SCIP notification number (Sweden) | 2adbd64c-bc93-45b8-bbef-6687522b5a7c | Ratings per | IEC/EN 60947-7-1 |
Rated current | 0.5A | Nominal voltage | 250V |
Reverse voltage | 1,000V | Connection technology | CAGE CLAMP? |
Actuation type | Operating tool | Connectable conductor materials | Copper |
Connectable conductor materials (note) | Terminating Aluminum ConductorsWAGO Spring-Clamp Terminal Blocks are suitable for solid aluminum conductors up to 4 mm2/12 AWG if WAGO “Alu-Plus” Contact Paste249-130is used for termination.“Alu-Plus” Contact Paste Advantages:Automatically destroys the oxide film during clamping.Prevents fresh oxidation at the clamping point.Prevents electrolytic corrosion between aluminum and copper conductors (in the same terminal block).Provides long-term protection against corrosion.Using terminal blocks with CAGE CLAMP?Spring Pressure Connection Technology,aluminum conductors must first be cleaned with a bladeand then immediately inserted into the clamping units filled with “Alu-Plus” contact paste.It is also possible to apply WAGO “Alu-Plus”additionallyon the whole surface of the aluminum conductor before termination.Please note that the nominal currents must be adapted to the reduced conductivity of the aluminum conductors::2.5 mm2 = 16 A4 mm2 = 22 A | Solid conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG |
Fine-stranded conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG | Strip length | 8 … 9?mm?/ 0.31 … 0.35?inches |
Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
