Product Model
281-327
Selling Points
- 1High-Quality Material: Made from durable polyamide (PA66) for long-lasting performance.
- 2Efficient Design: Oversized and 2 mm thick for enhanced stability and protection.
- 3Fire-Resistant: Meets stringent fire load standards with 0.065 MJ rating.
- 4Easy Installation: Designed for seamless integration with rail-mounted terminal blocks.
- 5Compliant and Reliable: RoHS compliant and suitable for various industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 53?mm?/ 2.087?inches |
Depth | 26.9?mm?/ 1.059?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.065MJ | Weight | 2.2g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332291057 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
