Product Model
281-343
Selling Points
- 1Made from high-quality materials for long-lasting performance.
- 22.5 mm thick and 38 mm high, perfect for space-efficient installations.
- 3Simple mounting options ensure quick setup in any electrical system.
- 4Suitable for end and intermediate connections in various electrical applications.
- 5Available in bulk quantities at an affordable price of $0.84 per unit.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2.5?mm?/ 0.098?inches | Height | 83?mm?/ 3.268?inches |
Depth | 38?mm?/ 1.496?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.119MJ | Weight | 4.3g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332295628 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
