Product Model
281-358
Selling Points
- 1The WAGO 281-358 terminal block features the patented CAGE CLAMP technology, providing automatic clamping without wire damage.
- 2No special wire preparation like crimps, ferrules, or tinning is required, simplifying the installation process.
- 3Suitable for a wide range of wire sizes from 0.08 mm² to 35 mm², making it versatile for various electrical applications.
- 4The clamping force adjusts automatically to the conductor cross-section, ensuring a secure connection.
- 5Constructed with stainless steel, the terminal block offers durability and resistance to corrosion, ensuring long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 61?mm?/ 2.402?inches |
Depth | 39?mm?/ 1.535?inches | Note (material data) | Information on material specifications can be found here |
Color | light gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.097MJ | Weight | 3.3g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332199353 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
