Product Model
281-665/281-400
Selling Points
- 14-Conductor Design: Ideal for multiple wiring needs in industrial settings.
- 2Integrated Diode 1N5408: Provides protection against voltage spikes and surges.
- 3CAGE CLAMP Technology: Ensures secure and reliable connections with aluminum conductors.
- 4DIN-Rail Compatibility: Suitable for 35 x 15 and 35 x 7.5 DIN rails.
- 5Gray Color and Polyamide Insulation: Durable and easy to integrate into your system.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 4 | Total number of potentials | 1 |
Number of levels | 1 | Width | 6?mm?/ 0.236?inches |
Height | 86?mm?/ 3.386?inches | Depth from upper-edge of DIN-rail | 29?mm?/ 1.142?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Center marking | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.207MJ | Weight | 13.7g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-27 |
eCl@ss 9.0 | 27-14-11-27 | ETIM 9.0 | EC000903 |
ETIM 8.0 | EC000903 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4050821275510 |
Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
SCIP notification number (Austria) | afc677b4-b8cf-4cbd-abd5-e9039bd42ab9 | SCIP notification number (Belgium) | 25fb1509-f7ee-46bd-b9c8-fa6b280e4d50 |
SCIP notification number (Bulgaria) | 9efa3a0e-1798-455e-ae8b-5c49a60568f0 | SCIP notification number (Czech Republic) | 0a762dc9-5f5d-4d71-9fb8-2b5067dcb705 |
SCIP notification number (Denmark) | 32652215-42d9-40d1-8e1c-4fa2f743ce50 | SCIP notification number (Finland) | c9c513f3-a40b-4bb5-bf2d-2860abdc68ec |
SCIP notification number (France) | 8d4b952f-2e11-4ca8-9864-ef60e58decb6 | SCIP notification number (Germany) | 3ff89411-a9a1-4532-8f1e-7a3927c1b6d3 |
SCIP notification number (Hungary) | d650b9e3-e79d-4596-a195-23164c56ea6e | SCIP notification number (Italy) | 2680d774-68cb-424b-af98-1d35178c4e54 |
SCIP notification number (Netherlands) | 0211d644-d599-485e-b3fc-48e70fb7fe43 | SCIP notification number (Poland) | 4c3ab72b-0c0a-4245-aa52-18b645d0128e |
SCIP notification number (Romania) | f205c07e-158a-48e4-bbdb-af10149b3508 | SCIP notification number (Sweden) | 48e66f3a-9669-4afc-9b20-4c3f6f4b6cd3 |
Ratings per | IEC/EN 60947-7-1 | Rated current | 1.5A |
Nominal voltage | 250V | Reverse voltage | 1,000V |
Connection technology | CAGE CLAMP? | Actuation type | Operating tool |
Connectable conductor materials | Copper | Connectable conductor materials (note) | Terminating Aluminum ConductorsWAGO Spring-Clamp Terminal Blocks are suitable for solid aluminum conductors up to 4 mm2/12 AWG if WAGO “Alu-Plus” Contact Paste249-130is used for termination.“Alu-Plus” Contact Paste Advantages:Automatically destroys the oxide film during clamping.Prevents fresh oxidation at the clamping point.Prevents electrolytic corrosion between aluminum and copper conductors (in the same terminal block).Provides long-term protection against corrosion.Using terminal blocks with CAGE CLAMP?Spring Pressure Connection Technology,aluminum conductors must first be cleaned with a bladeand then immediately inserted into the clamping units filled with “Alu-Plus” contact paste.It is also possible to apply WAGO “Alu-Plus”additionallyon the whole surface of the aluminum conductor before termination.Please note that the nominal currents must be adapted to the reduced conductivity of the aluminum conductors::2.5 mm2 = 16 A4 mm2 = 22 A |
Solid conductor | 0.08 … 4?mm2?/ 28 … 12?AWG | Fine-stranded conductor | 0.08 … 4?mm2?/ 28 … 12?AWG |
Strip length | 9 … 10?mm?/ 0.35 … 0.39?inches | Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
