Product Model
281-915/281-401
Selling Points
- 1Built with CAGE CLAMP technology for secure connections.
- 2Prevents electrolytic corrosion between aluminum and copper conductors.
- 3Compatible with DIN-rail 35 x 15 and 35 x 7.5.
- 4Equipped with diode 1N5408 for reliable protection.
- 5Push-in termination of solid and stranded conductors.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Clamping units | 2 | Total number of potentials | 1 |
Number of levels | 1 | Width | 6?mm?/ 0.236?inches |
Height | 59.2?mm?/ 2.331?inches | Depth from upper-edge of DIN-rail | 29?mm?/ 1.142?inches |
Design | horizontal type | Mounting type | DIN-35 rail |
Marking level | Center marking | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.143MJ | Weight | 8.8g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-27 |
eCl@ss 9.0 | 27-14-11-27 | ETIM 9.0 | EC000903 |
ETIM 8.0 | EC000903 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454197773 |
Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
SCIP notification number (Austria) | 99c1a4e8-069f-47e7-a4ac-f5d5cb0cc4c0 | SCIP notification number (Belgium) | bc0c32ef-1e8e-44bf-a227-badd30dda2d0 |
SCIP notification number (Bulgaria) | cacc476c-15eb-45c7-8b81-c4fae1c04928 | SCIP notification number (Czech Republic) | 1c6d3239-76a0-4ee7-8e18-9724e67064de |
SCIP notification number (Denmark) | 8a109fa9-e985-4a09-bc40-9aed98416562 | SCIP notification number (Finland) | 4a042368-25d9-4de2-bfd8-e2510ef6b75d |
SCIP notification number (France) | dc0a58c9-2f5d-48e6-a429-38a937a3305b | SCIP notification number (Germany) | ecc2746a-ee40-402d-823d-31864ccc354c |
SCIP notification number (Hungary) | f566b054-348e-4def-8582-1ce5698bd35f | SCIP notification number (Italy) | a76a0495-5917-48f8-bb7e-a7419b559660 |
SCIP notification number (Netherlands) | 6c573857-3526-4913-afe4-b0315bdb466c | SCIP notification number (Poland) | 72af28f4-ab73-43da-9737-432df1d5ddaf |
SCIP notification number (Romania) | 7fa5b6b4-2304-40fb-b296-da5260e70d7e | SCIP notification number (Sweden) | 5024b483-0492-47cb-be80-5bbbb2493dc7 |
Ratings per | IEC/EN 60947-7-1 | Rated current | 1.5A |
Nominal voltage | 250V | Reverse voltage | 1,000V |
Connection technology | CAGE CLAMP? | Actuation type | Operating tool |
Connectable conductor materials | Copper | Connectable conductor materials (note) | Terminating Aluminum ConductorsWAGO Spring-Clamp Terminal Blocks are suitable for solid aluminum conductors up to 4 mm2/12 AWG if WAGO “Alu-Plus” Contact Paste249-130is used for termination.“Alu-Plus” Contact Paste Advantages:Automatically destroys the oxide film during clamping.Prevents fresh oxidation at the clamping point.Prevents electrolytic corrosion between aluminum and copper conductors (in the same terminal block).Provides long-term protection against corrosion.Using terminal blocks with CAGE CLAMP?Spring Pressure Connection Technology,aluminum conductors must first be cleaned with a bladeand then immediately inserted into the clamping units filled with “Alu-Plus” contact paste.It is also possible to apply WAGO “Alu-Plus”additionallyon the whole surface of the aluminum conductor before termination.Please note that the nominal currents must be adapted to the reduced conductivity of the aluminum conductors::2.5 mm2 = 16 A4 mm2 = 22 A |
Solid conductor | 0.08 … 4?mm2?/ 28 … 12?AWG | Fine-stranded conductor | 0.08 … 4?mm2?/ 28 … 12?AWG |
Strip length | 9 … 10?mm?/ 0.35 … 0.39?inches | Wiring direction | Front-entry wiring |
Specifications may be subject to change without notice
