Product Model
283-330
Selling Points
- 1The WAGO 283-330 features the patented CAGE CLAMP technology, which automatically connects solid or stranded wires without the need for crimps, ferrules, or tinning.
- 2Designed to handle up to 800V, making it suitable for a wide range of industrial applications.
- 3No special wire preparation is required, reducing installation time and increasing efficiency.
- 4The clamping force adjusts automatically to the conductor cross-section, ensuring a secure connection.
- 5Built with stainless steel for long-lasting performance and resistance to environmental factors.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2.5?mm?/ 0.098?inches | Height | 94.4?mm?/ 3.717?inches |
Depth | 36.5 mm / 1.437 inches | Note (material data) | Information on material specifications can be found here |
Color | light gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.182MJ | Weight | 6.1g |
Processing temperature | -35 … +85?°C | Continuous operating temperature | -60 … +105?°C |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332580106 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
