Product Model
284-341
Selling Points
- 1Automatic Clamping: The CAGE CLAMP technology ensures secure connections without damaging wires.
- 2High Voltage Rating: Supports up to 800V, making it suitable for various electrical applications.
- 3Compact Design: Ideal for space-constrained environments with a width of 4.2mm.
- 4Versatile Conductors: Compatible with AWG 22 to AWG 14 conductors.
- 5Easy Installation: No need for specialized tools; easy to install in both factory and field settings.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2.5?mm?/ 0.098?inches | Height | 97.4?mm?/ 3.835?inches |
Depth | 35?mm?/ 1.378?inches | Note (material data) | Information on material specifications can be found here |
Color | light gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.163MJ | Weight | 5.4g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332296120 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
