Product Model
284-345
Selling Points
- 11 mm Thick and Durable: Made from high-quality material for long-lasting performance.
- 2Orange Color: Easy to identify and integrate into your electrical systems.
- 3UL94 V0 Flammability Class: Meets stringent safety standards for electrical components.
- 4Compatible with 280-633 Terminal Blocks: Seamless integration with WAGO's 280-633 series.
- 5Compact Dimensions (26.5 mm Depth, 79 mm Height): Space-efficient design for rail and chassis mounting.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1?mm?/ 0.039?inches | Height | 79?mm?/ 3.11?inches |
Depth | 26.5?mm?/ 1.043?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.056MJ | Weight | 1.9g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332195942 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
