Product Model
286-352/004-000
Selling Points
- 1High-Quality 4PDT Relay: The WAGO 286-352/004-000 relay module offers 4 make contacts for reliable switching.
- 224 VDC Coil Voltage: Compatible with 24 VDC coil voltage, ensuring efficient operation in various industrial settings.
- 3IP20 Protection: Designed with IP20 protection, providing a safe and durable solution for your applications.
- 4Compact Dimensions: Measuring 3.248 in H x 0.984 in W x 2.047 in D, this relay module is compact and easy to integrate.
- 5RoHS Compliant: Compliant with RoHS standards, ensuring environmental sustainability in your projects.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated voltage | 250V | Rated surge voltage | 2.5kV |
Pollution degree | 2 | Dielectric strength (control/load circuit) (AC, 1?min) | 1.5?kVrms |
Protection type | IP20 | Width | 25?mm?/ 0.984?inches |
Height | 52 mm / 2.047 inches | Depth from upper-edge of DIN-rail | 82.5 mm / 3.248 inches |
Note (dimensions) | Depth including carrier terminal block | Mounting type | Pluggable module for receptacle terminal blocks |
Note (material data) | Information on material specifications can be found here | Color | gray |
Fire load | 15.112MJ | Weight | 40.1g |
Ambient temperature (operation at U<sub>N</sub>) | -25 … +70 °C | Ambient temperature (storage) | -25 … +70 °C |
Processing temperature | -25 … +50?°C | Relative humidity | 5 … 85?% (no condensation permissible) |
Operating altitude (max.) | 2000m | Standards/specifications | EN 60664-1 |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-37-16-01 |
eCl@ss 9.0 | 27-37-16-01 | ETIM 9.0 | EC001437 |
ETIM 8.0 | EC001437 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 10?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4055143104760 |
Customs tariff number | 8536490050 | CAS-No. | 1303-86-2 |
REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 6(c) | SCIP notification number (Austria) | bf930b2d-e357-465c-96d7-3e8b0bf89a2b |
SCIP notification number (Belgium) | bc2ec3b4-0412-48bd-ad5a-ecd39196622d | SCIP notification number (Bulgaria) | 2cb282cd-cb32-42b2-8779-4fc429e12ee1 |
SCIP notification number (Czech Republic) | 1452ea77-3381-49c2-bacd-0c4f0ca3b2ac | SCIP notification number (Denmark) | d9ee84a9-3db0-4341-abd7-ca0c21680530 |
SCIP notification number (Finland) | 0237c6af-7920-44d7-8b0d-81311cd6108b | SCIP notification number (France) | d16fcd46-55d1-4de7-8287-7304e4eb1ade |
SCIP notification number (Germany) | 1f1f3731-59f5-4065-b4e7-c49b165fb577 | SCIP notification number (Hungary) | 87cee33c-de33-4603-b146-70b65247a0f4 |
SCIP notification number (Italy) | f25e43d5-92e9-43f4-82ea-4dc5d836247b | SCIP notification number (Netherlands) | 52650da2-2998-46ec-9897-d3d91b1a5fae |
SCIP notification number (Poland) | 4e8bd6a1-1551-4be2-9d73-5c561605e082 | SCIP notification number (Romania) | 3653fb6d-9806-484e-9bbd-2ed40d1bdd7f |
SCIP notification number (Sweden) | 3f5e52e7-3e95-402e-b70d-4fbfa9d9fc49 | Nominal input voltage U<sub>N</sub> | DC?24?V |
Input voltage range | -30 … +25?% | Nominal input current at U<sub>N</sub> | 9?mA |
Number of make/switch-on contacts | 4 | Contact material (relay) | AgNi + Au |
Limiting continuous current | 5?A | Switching Voltage, Max. | AC?250?V |
Pull-in time (typ.) | 10ms | Drop-out time (typ.) | 5ms |
Bounce time (typ.) | 2ms |
Specifications may be subject to change without notice
