Product Model
286-516
Selling Points
- 1Reliable Operation: Designed to operate with a nominal input voltage of 230VAC.
- 2High Current Handling: Capable of handling a limiting continuous current of 7A.
- 3Versatile Contacts: Equipped with 2 changeover contacts for flexible circuit configurations.
- 4Easy Monitoring: Features a red status indicator for quick status checks.
- 5Compact Design: Module width is 15 mm, making it suitable for space-constrained applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated voltage | 250V | Rated surge voltage | 4kV |
Pollution degree | 2 | Dielectric strength (control/load circuit) (AC, 1?min) | 2?kVrms |
Dielectric strength (open contact) (AC, 1?min) | 1?kVrms | Dielectric strength (load/load circuit) (AC, 1?min) | 1.5?kVrms |
Protection type | IP20 | Width | 20?mm?/ 0.787?inches |
Height | 52 mm / 2.047 inches | Depth from upper-edge of DIN-rail | 82.5 mm / 3.248 inches |
Note (dimensions) | Depth including carrier terminal block | Mounting type | Pluggable module for receptacle terminal blocks |
Note (material data) | Information on material specifications can be found here | Color | gray |
Fire load | 0.413MJ | Weight | 35.2g |
Ambient temperature (operation at U<sub>N</sub>) | -25 … +40 °C | Ambient temperature (storage) | -25 … +70 °C |
Processing temperature | -25 … +50?°C | Relative humidity | 5 … 75?% (no condensation permissible) |
Operating altitude (max.) | 2000m | Standards/specifications | EN 60664-1 |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-37-16-01 |
eCl@ss 9.0 | 27-37-16-01 | ETIM 9.0 | EC001437 |
ETIM 8.0 | EC001437 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 15?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332291507 |
Customs tariff number | 8536490050 | RoHS Compliance Status | Compliant,No Exemption |
Nominal input voltage U<sub>N</sub> | AC?230?V | Input voltage range | ±10?% |
Nominal input current at U<sub>N</sub> | 4?mA | Number of changeover contacts | 2 |
Contact material (relay) | AgNi 0.15 | Limiting continuous current | 7?A |
Switching Voltage, Max. | AC?250?V | Switching power (resistive) max. | AC?1750?VA |
Pull-in time (typ.) | 15ms | Drop-out time (typ.) | 3ms |
Bounce time (typ.) | 2ms | Electrical life (NO; resistive load; 23?°C) | 100?x 103 switching operations |
Mechanical life | 30?x 10? switching operations | Status indicator | Red LED |
Specifications may be subject to change without notice
