Product Model
286-891
Selling Points
- 1AC/DC 230 V
- 26.3A
- 30.5 mA in case of blown fuse
- 4Pluggable module for carrier terminal blocks
- 5Gray, fire load 0.263 MJ, weight 14.1 g
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Nominal operating voltage | AC/DC?230?V | Fuse capacity (max.) | 6.3A |
Leakage current in case of a blown fuse | 0.5mA | Rated voltage | 250V |
Rated surge voltage | 4kV | Pollution degree | 3 |
Width | 10?mm?/ 0.394?inches | Height | 52 mm / 2.047 inches |
Depth from upper-edge of DIN-rail | 82.5 mm / 3.346 inches | Note (dimensions) | Depth including carrier terminal block |
Mounting type | Pluggable module for receptacle terminal blocks | Housing design | Plug for carrier terminal blocks |
Color | gray | Fire load | 0.492MJ |
Weight | 14.1g | Ambient temperature (operation) | -25 … +40 °C |
Relative humidity | 5 … 95?% (no condensation permissible) | Operating altitude (max.) | 2000m |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-14-11-16 |
eCl@ss 9.0 | 27-14-11-16 | ETIM 9.0 | EC000899 |
ETIM 8.0 | EC000899 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 30?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454376482 |
Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
