Product Model
288-001
Selling Points
- 1Versatile Mounting Options: Suitable for both screw and DIN rail mounting.
- 2Compact Design: Gray color, 45.5 mm width, 23.5 mm height, and 65.5 mm depth.
- 3Easy Installation: Simple to insert wires using a special lever tool or flat screwdriver.
- 4Durable Construction: Gray, closed housing with no shielding required.
- 5Reproducible and Repairable: Facilitates cabinet documentation and ensures reproducibility and repairability by others.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note | Mounting feet must be ordered separately! | Width | 45.5?mm?/ 1.791?inches |
Height | 65.5?mm?/ 2.579?inches | Depth from upper-edge of DIN-rail | 23.5?mm?/ 0.925?inches |
Mounting type | DIN-35 rail | Color | gray |
Fire load | 0.237MJ | Weight | 7.9g |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-18-27-02 |
eCl@ss 9.0 | 27-18-27-02 | ETIM 9.0 | EC001031 |
ETIM 8.0 | EC001031 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332159548 |
Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
