Product Model
289-198
Selling Points
- 1High-Speed Connectivity: Supports Cat. 6A for fast data transfer.
- 2Dual RJ-45 Connectors: Enables secure and reliable connections with two RJ-45 ports.
- 3Shield Connection: Provides enhanced signal integrity with shielded connections.
- 4Mounting Carrier: Easy installation with a mounting carrier for secure placement.
- 5Durable Design: Built to withstand demanding industrial environments with a robust design.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Specialty functions | with shield connection | Protection type | IP20 |
Mating cycles | 750 | Connection cable | Cat. 6A (min.) |
Width | 18?mm?/ 0.709?inches | Height | 90?mm?/ 3.543?inches |
Depth from upper-edge of DIN-rail | 59?mm?/ 2.323?inches | Mounting type | DIN-35 rail |
Housing design | Mounting carrier | Contact material (connector) | Spring steel |
Weight | 34g | Ambient temperature (operation) | -10 … +60 °C |
Ambient temperature (storage) | -40 … +70 °C | Relative humidity | 95% (non-condensing) |
ETIM 9.0 | EC002780 | ETIM 8.0 | EC002780 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
Packaging type | bag | Country of origin | PL |
GTIN | 4066966083491 | Customs tariff number | 8536904000 |
RoHS Compliance Status | Compliant,No Exemption | Pluggable connector | RJ-45 (shielded) |
Pole number 1 | 8 | Connection type 1 | System |
Connector 2 | RJ-45 (shielded) | Pole number (2) | 8 |
Connection type 2 | System |
Specifications may be subject to change without notice
