Product Model
289-576
Selling Points
- 1Supports up to 2 A of current.
- 2IP20 protection for reliable performance in various environments.
- 315-pin D-sub female connector for system connections and 16-pin field connections.
- 4Mounts easily on DIN-35 rail with a secure strain relief.
- 5Meets EN 61010-2-201 and UL 508 standards for safety and performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Operating voltage | ≤?AC/DC?125?V | Nominal current | 2A |
Contact resistance (max.) | 30?mΩ | Specialty functions | with shield connection |
Rated voltage | 125V | Rated surge voltage | 0.8kV |
Pollution degree | 2 | Protection type | IP20 |
Insulation type | Basic insulation | Performance level | 2 / 200 mating cycles |
Strain relief | UNC 4-40 stud bolt | Width | 43?mm?/ 1.693?inches |
Height | 85?mm?/ 3.346?inches | Depth from upper-edge of DIN-rail | 34?mm?/ 1.339?inches |
Mounting type | DIN-35 rail | Housing design | Mounting carrier |
Contact material (connector) | Au over Ni | Fire load | 0.929MJ |
Weight | 58.8g | Ambient temperature (operation) | -20 … +50 °C |
Ambient temperature (storage) | -40 … +70 °C | Relative humidity | 85% (non-condensing) |
Standards/specifications | EN 61010-2-201 | Product Group | 6 (INTERFACE ELECTRONIC) |
eCl@ss 10.0 | 27-14-11-52 | eCl@ss 9.0 | 27-14-11-52 |
ETIM 9.0 | EC002780 | ETIM 8.0 | EC002780 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 7?(1)?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4045454417925 | Customs tariff number | 8536904000 |
RoHS Compliance Status | Compliant,No Exemption | Pluggable connector | D-subminiature female connector |
Pole number 1 | 15 | Connection type 1 | System |
Note (conductor cross-section) | 12 AWG: THHN, THWN | Mating direction | vertical |
Design 2 | PCB terminal blocks (double-row) | Pole number (2) | 16 |
Connection type 2 | Field | Connection technology 2 | CAGE CLAMP? |
WAGO connector 2 | WAGO 236 Series | Solid conductor 2 | 0.08 … 2.5?mm2?/ 28 … 12?AWG |
Fine-stranded conductor 2 | 0.08 … 2.5?mm2?/ 28 … 12?AWG | Strip length 2 | 5 … 6?mm?/ 0.2 … 0.24?inches |
Specifications may be subject to change without notice
