Product Model
289-664
Selling Points
- 18-Channel Digital Input: Handle multiple signals with ease.
- 23-Wire Connection: Simplified setup with a single cable.
- 3CAGE CLAMP Technology: Secure and reliable connections.
- 4Compact Design: Measures 85 mm in depth, 56 mm in width.
- 5Industrial-Grade Quality: Built for robust performance in harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Inputs/outputs | 8-Channel Digital Input | Circuit type | 3-wire connection |
Operating voltage | ≤100?VAC;?≤125?VDC | Total current | 8A |
Rated voltage | 100V | Rated surge voltage | 0.8kV |
Pollution degree | 2 | Protection type | IP20 |
Width | 56?mm?/ 2.205?inches | Height | 85?mm?/ 3.346?inches |
Depth from upper-edge of DIN-rail | 34?mm?/ 1.339?inches | Mounting type | DIN-35 rail |
Housing design | Mounting carrier | Fire load | 1.011MJ |
Weight | 73g | Ambient temperature (operation) | -20 … +50 °C |
Ambient temperature (storage) | -40 … +70 °C | Relative humidity | 85% (non-condensing) |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-14-11-52 |
eCl@ss 9.0 | 27-14-11-52 | ETIM 9.0 | EC002780 |
ETIM 8.0 | EC002780 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 5?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454193294 |
Customs tariff number | 8536904000 | RoHS Compliance Status | Compliant,No Exemption |
Pluggable connector | WAGO 236 Series | Connection technology | CAGE CLAMP? |
WAGO connector | WAGO 236 Series | Solid conductor | 0.08 … 2.5?mm2?/ 28 … 12?AWG |
Fine-stranded conductor | 0.08 … 2.5?mm2?/ 28 … 12?AWG | Note (conductor cross-section) | 12 AWG: THHN, THWN |
Strip length | 5 … 6?mm?/ 0.2 … 0.24?inches |
Specifications may be subject to change without notice
