Product Model

289-822

Manufacturer

wago

Category

Interface Modules

Product ID

43764

In Stock
Last updated: 2025/4/17
View Specifications
wago 289-822

Selling Points

  • 1Robust Connectivity: Equipped with a 62-pin HD-Sub-D male connector and a 64-pin spring CAGE CLAMP for reliable system and field connections.
  • 2Rackmount Design: Specifically designed for 19" rack installations, ensuring easy integration into existing infrastructure.
  • 3High-Temperature Operation: Operates in ambient temperatures ranging from -20°C to +55°C, making it suitable for various industrial environments.
  • 4IP20 Protection: Offers IP20 protection, ensuring safe operation in harsh conditions.
  • 5Versatile Cable Accommodation: Supports cables from 0.08 to 2.5mm², accommodating a wide range of cable sizes for flexible connectivity options.
Product Details
289-822
wago

Technical Specifications

Detailed engineering parameters based on manufacturer documentation

ParameterValueParameterValue
Operating voltage
≤?AC/DC?125?V
Nominal current
1A
Contact resistance (max.)
10?mΩ
Specialty functions
with shield connection
Rated voltage
125V
Rated surge voltage
0.8kV
Pollution degree
2
Protection type
IP20
Performance level
2 / 400 mating cycles
Strain relief
UNC 4-40 stud bolt
Width
80?mm?/ 3.15?inches
Height
27?mm?/ 1.062?inches
Depth
132?mm?/ 5.197?inches
Mounting type
Module for 19” racks
Housing design
Module for 19” racks
Contact material (connector)
Au over Ni
Fire load
0.853MJ
Weight
151.3g
Ambient temperature (operation)
-20 … +55 °C
Ambient temperature (storage)
-40 … +70 °C
Product Group
6 (INTERFACE ELECTRONIC)
eCl@ss 10.0
27-14-11-52
eCl@ss 9.0
27-14-11-52
ETIM 9.0
EC002780
ETIM 8.0
EC002780
ECCN
NO US CLASSIFICATION
PU (SPU)
8?(1)?pcs
Packaging type
box
Country of origin
DE
GTIN
4045454591915
Customs tariff number
8536904000
RoHS Compliance Status
Compliant,No Exemption
Pluggable connector
HD D-sub male connector
Pole number 1
62
Connection type 1
System
Mating direction
vertical
Pole number (2)
64
Connection type 2
Field
Connection technology 2
CAGE CLAMP?
WAGO connector 2
WAGO 739 Series
Solid conductor 2
0.08 … 1.5?mm2?/ 28 … 14?AWG
Fine-stranded conductor 2
0.08 … 1.5 mm2 / 28 … 12 AWG
Strip length 2
5 … 6?mm?/ 0.2 … 0.24?inches

Specifications may be subject to change without notice
