Product Model
709-112
Selling Points
- 1Insulated wire commoning chain with 3 connections.
- 2Measuring 2 x 170 mm, perfect for rail/chassis terminal blocks.
- 3Rated current of 24 A for reliable performance.
- 4Black color and ultrasonically tip-bonded conductors.
- 5Compliant with ROHS regulations for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Conductor preparation | ultrasonically tip-bonded | Note (material data) | Information on material specifications can be found here |
Color | black | Fire load | 0.093MJ |
Weight | 15.4g | Product Group | 2 (Terminal Block Accessories) |
eCl@ss 10.0 | 27-14-11-40 | eCl@ss 9.0 | 27-14-11-40 |
ETIM 9.0 | EC000489 | ETIM 8.0 | EC000489 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 50?(1)?pcs |
Packaging type | Box | Country of origin | DE |
GTIN | 4017332258944 | Customs tariff number | 8544429090 |
RoHS Compliance Status | Compliant,No Exemption | Rated current | 24A |
Specifications may be subject to change without notice
