Product Model
734-159
Selling Points
- 1100% Mismating Protection: Ensures only compatible halves can be connected, preventing errors.
- 2Angled Solder Pins: Convenient for horizontal or vertical PCB mounting with ease.
- 3Light Gray Color: Easy to identify and integrate into your circuit design.
- 4High-Quality Materials: Made with polyamide insulation and electrolytic copper contacts for durability.
- 5Compliant with DIN EN 61984: Meets safety standards for connectors without breaking capacity.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Suitable | for male connectors | Note (material data) | Information on material specifications can be found here |
Color | black | Material group | I |
Insulation material (main housing) | Polyphthalamide (PPA GF) | Flammability class per UL94 | V0 |
Fire load | 0.002MJ | Weight | 0.1g |
Product Group | 3 (Multi Conn. System) | eCl@ss 10.0 | 27-44-04-92 |
eCl@ss 9.0 | 27-44-04-02 | ETIM 9.0 | EC002848 |
ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 500?(100)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454535094 |
Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
