Product Model
745-584
Selling Points
- 1High current rating up to 76 A.
- 2Silver-colored, unplated for durability.
- 34-way jumper assignment for versatile use.
- 4Compatible with 745 Series and 2716 Series.
- 5Meets RoHS compliance standards for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Pin spacing | 10?mm?/ 0.394?inches | Jumper assignment | 1-2-3-4 |
Suitable | for 745 Series (16 mm2) and 2716 Series | Note (material data) | Information on material specifications can be found here |
Color | silver-colored | Contact material | Copper alloy |
Contact plating | Tin | Weight | 7.8g |
Product Group | 4 (Printed Circuit Connectors) | eCl@ss 10.0 | 27-14-11-40 |
eCl@ss 9.0 | 27-44-04-92 | ETIM 9.0 | EC000489 |
ETIM 8.0 | EC000489 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 200?(50)?pcs | Packaging type | box |
Country of origin | CH | GTIN | 4044918303507 |
Customs tariff number | 8536698000 | RoHS Compliance Status | Compliant,No Exemption |
Rated current | 76A |
Specifications may be subject to change without notice
