Product Model
750-940
Selling Points
- 1High-speed data transfer capabilities for efficient automation.
- 2Robust connectivity options including Ethernet and RS-232.
- 3Compact design for easy integration into complex control systems.
- 4Durable construction with IP20 protection for harsh environments.
- 5Compatible with various industrial protocols for seamless integration.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Communications | RS-485 interface | Device-specific | Number of devices that can be connected in series in Modbus mode: max. 10; ESP3 mode: 1:1 connection |
Radio technology | EnOcean | Frequency band | 868 MHz |
Transmission range | approx. 30 m within buildings; >100 m in open space | Antenna | Internal (external antenna optional via SMA socket) |
Transmission rate | 9.6/115.2 kBd | Data width | 50 bytes |
Supply voltage | 24?VDC (18 … 31.2?V) | Overvoltage category | III |
Connection technology: communication/fieldbus | 1 x RS-485 connection: 5-pole, 2-conductor compact PCB connectors with PUSH WIRE? (252-155 is included) | Connection technology: supply | 1 x 2-pole, 2-conductor compact PCB connectors with PUSH WIRE? (252-152 is included) |
Connection technology: antenna | 1 x SMA socket for external antenna | Connection type 1 | Communication |
Solid conductor | 0.4 … 0.8?mm2?/ 26 … 20?AWG | Strip length | 6 … 7?mm?/ 0.24 … 0.28?inches |
Connection type 2 | Power supply | Solid conductor 2 | 0.4 … 0.8?mm2?/ 26 … 20?AWG |
Strip length 2 | 6 … 7?mm?/ 0.24 … 0.28?inches | Width | 95?mm?/ 3.740?inches |
Height | 36?mm?/ 1.417?inches | Depth | 95?mm?/ 3.740?inches |
Diameter | 95mm | Weight | 97g |
Conformity marking | CE | Ambient temperature (operation) | 0 … +55 °C |
Ambient temperature (storage) | -20 … +85 °C | Protection type | IP30 |
Pollution degree | 2 per EN 60664-1, EN 61131-2 | Mounting position | Horizontal left, horizontal right, horizontal top, horizontal bottom, vertical top and vertical bottom |
EMC immunity to interference | per EN 61000-6-2 | EMC emission of interference | per EN 61000-6-3 + A1 |
ETIM 9.0 | EC001604 | ETIM 8.0 | EC001604 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
Packaging type | Box | Country of origin | DE |
GTIN | 4066966154894 | Customs tariff number | 84733080000 |
CAS-No. | 1303-86-2 | REACH Candidate List Substance | Diboron trioxide |
RoHS Compliance Status | Compliant,With Exemption | RoHS Exemption | 6(c) |
SCIP notification number (Austria) | f38f953b-acc6-4140-9cfc-3cc89b20d806 | SCIP notification number (Belgium) | 7efbf432-0309-4ecf-902e-849c230e121d |
SCIP notification number (Bulgaria) | db79e5c5-c50c-421f-af56-a44f476e877c | SCIP notification number (Czech Republic) | ffc70deb-95a2-42e9-88c8-118ddcbe5a41 |
SCIP notification number (Denmark) | 7e1e2149-d9a8-4aa2-b82f-b374c1720246 | SCIP notification number (Finland) | 03ca7456-32c9-432d-b88e-71d6609472fe |
SCIP notification number (France) | a652e5b9-9cfa-457d-b786-a9ff0fdabdc4 | SCIP notification number (Germany) | 8e9f1628-6619-44d9-8934-f2d421821616 |
SCIP notification number (Hungary) | 4beca8d8-d1eb-4df2-9aa6-950f0fb40a23 | SCIP notification number (Italy) | ecb5dcfe-994a-47fd-bb41-1aab19c12e63 |
SCIP notification number (Netherlands) | 56eeff61-2e4e-4387-b679-b19565e20406 | SCIP notification number (Poland) | d2e22828-db60-4780-8021-5e37d79451d7 |
SCIP notification number (Romania) | 0f2c93a7-04e3-47d6-a93d-5ec70048efa8 | SCIP notification number (Sweden) | 7af5f0a7-a7c0-4c8a-bc41-9aec7cea2ad7 |
Specifications may be subject to change without notice
