Product Model
750-965
Selling Points
- 1Compact Design: Extremely compact I/O nodes with up to 16 channels in a 12 mm housing.
- 2Modular Flexibility: Each node can be configured to meet each channel’s requirements, supporting digital and analog I/O modules.
- 3Fieldbus Independence: Supports numerous fieldbus systems and ETHERNET standards for maximum flexibility.
- 4Pluggable Connections: 100% compatible with the 750 Series, featuring detachable wiring interfaces for easy module replacement.
- 5Reliable Connections: CAGE CLAMP® spring pressure connections ensure superior reliability and secure connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Connection type | D-sub 9 plug | Number of poles | 9 |
Communication/fieldbus | CC-Link | Transmission rate | - |
Connection type 1 | CAGE CLAMP?terminal strip with locking slide (218 Series) | Solid conductor | 0.08 … 0.5?mm2?/ 28 … 20?AWG |
Strip length | 5 … 6?mm?/ 0.2 … 0.24?inches | Width | 45?mm?/ 1.772?inches |
Height | 16?mm?/ 0.63?inches | Depth | 54?mm?/ 2.126?inches |
Connectable sheathed cable diameter | 4.5 … 9.5?mm | Cable glands (number) | 2 |
Housing material | PA66-105-V2 | Weight | 34.1g |
Color | light gray | Ambient temperature (operation) | 0 … +60 °C |
Ambient temperature (storage) | -25 … +85 °C | Protection type | IP20 |
Relative humidity (without condensation) | 95% | Fire load | 0.29MJ |
Product Group | 15 (I/O System) | eCl@ss 10.0 | 27-24-26-92 |
eCl@ss 9.0 | 27-24-26-92 | ETIM 9.0 | EC002584 |
ETIM 8.0 | EC002584 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 1?pcs | Packaging type | bag |
Country of origin | DE | GTIN | 4050821096030 |
Customs tariff number | 8517620090 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
