Product Model
756-6501/040-010
Selling Points
- 1Halogen-Free Cable: Ensures safety and compliance with environmental regulations.
- 24-Pole Connectivity: Provides robust and reliable connections for sensors and actuators.
- 3Straight M12A Socket & M8 Plug: Easy installation with no need for bending or twisting.
- 4Polyurethane Cable Sheath: Durable and resistant to various environmental conditions.
- 5Compliant with RoHS: Meets stringent environmental standards for sustainable manufacturing.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
ETIM 9.0 | EC001855 | ETIM 8.0 | EC001855 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1 pcs |
Packaging type | unpacked | Country of origin | CN |
GTIN | 4066966501643 | Customs tariff number | 85444290900 |
RoHS Compliance Status | Compliant,No Exemption | Operating voltage | 300 VDC |
Protection type | IP67 | Ambient (operating) temperature (static) | -40 … +80 °C |
Ambient (operating) temperature (dynamic) | -20 … +60 °C | Cable length | 1m |
Sheathed cable color | black | Connection type | M12 Socket - M8 plug |
Number of poles | 4 | Cable connection direction to mating direction | 0° |
Cable connection direction to mating direction (2) | 0° | Connector interface coding (cable/adapter) 1 1 | A-coded |
Specifications may be subject to change without notice
