Product Model
757-164
Selling Points
- 1Reliable Connectivity: 6-way M12 connectors ensure secure and efficient signal transmission.
- 2Durable Design: IP67 rated for protection against dust and water, ensuring long-lasting performance.
- 3Versatile Mounting: Screw mounting type allows for easy installation in various industrial settings.
- 4Wide Temperature Range: Operates from -25°C to +80°C, suitable for diverse environmental conditions.
- 5Halogen-Free Housing: Made from PA 66 (UL 94 V0) material, ensuring safety and compliance with environmental regulations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Contact resistance (max.) | 0.01Ω | Supply voltage | 10 … 30?VDC;?Rated voltage: 32 V ~ rms |
Current carrying capacity (signal connections) | 2A | Current carrying capacity (supply connections) | 9A |
Rated value of electrical isolation | 500V | Functionally separated potential groups | Kontakt/Kontakt |
Insulation resistance | >109Ω | Signal characteristics | PNP |
Indicators | LED (A) yellow: Signal status (1 x per contact); LED (U) green: Sensor/actuator box status | Connection technology: inputs / outputs | 6 x M12 socket; 4-pole; incl. ground |
Connection technology: trunk cable | 1 x M23 plug; 12-pole | Width | 60?mm?/ 2.362?inches |
Height | 34?mm?/ 1.339?inches | Depth | 123?mm?/ 4.843?inches |
Mounting type | Screw mounting | Weight | 195g |
Housing material | PA 66 (UL 94 V0); RAL 7035; silicon and halogen free | Material properties of the connections | Contact: CuSn, nickel base-coat plating and 0.8 μm gold-plated; Threaded bush: die-cast Zn, nickel-plated; Seal: Viton; 50 mating cycles |
Encapsulation | Fully encapsulated with conformal coating (UL 94 V0) | Ambient temperature (operation) | -25 … +80 °C |
Protection type | IP67 | Note on protection type | per EN 60529 (NEMA 6 & 6P) in fully locked position with its plugs or protective caps |
Pollution degree | 3 per VDE 0110 | Vibration resistance | per IEC 60068-2-6 |
Shock resistance | per IEC 60068-2-27 | eCl@ss 10.0 | 27-44-01-11 |
eCl@ss 9.0 | 27-44-01-08 | ETIM 9.0 | EC003558 |
ETIM 8.0 | EC003558 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 1?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4050821054290 |
Customs tariff number | 8536698000 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 6(c) | SCIP notification number (Austria) | 0eba7b55-0c35-4b32-9335-d0114961970e |
SCIP notification number (Belgium) | 1b37e433-1351-4f0c-8bbf-27350d26dd3e | SCIP notification number (Bulgaria) | 8421cbb3-be38-47b8-9582-e1c2a06a90d6 |
SCIP notification number (Czech Republic) | 7bd637ce-8944-428e-a4f8-ec23460634ee | SCIP notification number (Denmark) | e5b2ec1e-be55-4926-912c-9321a337b772 |
SCIP notification number (Finland) | be43c6dc-e867-4103-b7f0-3597cba464e5 | SCIP notification number (France) | ef08c6cf-518c-42f3-b60b-e3babb3e4e35 |
SCIP notification number (Germany) | 825a7886-9dd4-4dc6-911c-e943a2110070 | SCIP notification number (Hungary) | b3d2cd58-562b-4943-b2c1-5ab7be0c631b |
SCIP notification number (Italy) | 851bd862-c1a1-4232-bfd3-ad2dc036f93d | SCIP notification number (Netherlands) | 1a2573cc-b74f-4538-8dad-ea1d93b48a2a |
SCIP notification number (Poland) | 0a171249-3c04-40d0-8ff7-8124285f7d1a | SCIP notification number (Romania) | d8d6cfab-adc8-4a4e-b4c8-3a2eb8e34609 |
SCIP notification number (Sweden) | 2e3b824f-88f3-4da6-a312-b94249da3c7e |
Specifications may be subject to change without notice
