Product Model
757-702
Selling Points
- 1High-Performance Signal Distribution: The WAGO 757-702 efficiently distributes signals with PNP characteristics, ensuring reliable data transmission.
- 2IP67 Protection: Fully encapsulated and conformal-coated, this signal distributor offers complete protection against harsh industrial environments.
- 3Durable Materials: Constructed with CuSn contacts, nickel base-coat plating, and 0.8 μm gold-plating, ensuring long-lasting performance.
- 4Versatile Connectivity: Equipped with 14 M12 connectors and a 16-pole heavy-duty industrial pluggable connector for easy integration.
- 5Operational Flexibility: Compatible with ambient temperatures ranging from -25°C to +80°C, making it suitable for various industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Supply voltage | 10 … 30?VDC;?Rated voltage: 32 V ~ rms | Current carrying capacity (signal connections) | 2A |
Current carrying capacity (supply connections) | 9A | Signal characteristics | PNP |
Connection technology: inputs / outputs | 14 x M12 socket; 4-pole; incl. ground | Connection technology: trunk cable | 1 x Fixed connecting cable |
Weight | 1000g | Bending radius | 10 x cable diameter (min.) for flexible application |
Material properties of the connections | Contact: CuSn, nickel base-coat plating and 0.8 μm gold-plated; Threaded bush: die-cast Zn, nickel-plated; Seal: Viton; 50 mating cycles | Cable grip | Alkali-resistant PVDF/TPE materials |
Ambient temperature (operation) | -25 … +80 °C | Ambient (operating) temperature (dynamic) | -5 … +80 °C |
Ambient (operating) temperature (static) | -40 … +90 °C | Pollution degree | 3 per VDE 0110 |
Product Group | 23 (I/O passive and accessories) | ECCN | NO US CLASSIFICATION |
PU (SPU) | 1?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4050821290759 |
Customs tariff number | 8536694040 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,With Exemption |
RoHS Exemption | 6(c) | SCIP notification number (Austria) | f359d5ba-d53d-428d-9866-b5bd60dfce84 |
SCIP notification number (Belgium) | eefd8798-f48f-45ea-ac78-418d9c78dfc1 | SCIP notification number (Bulgaria) | d4b92515-a0a6-4a24-b6f5-6b09fdd4c6d0 |
SCIP notification number (Czech Republic) | 46f22c86-d518-4177-9c38-68ab98a3f38e | SCIP notification number (Denmark) | 5d95b25d-bd1a-4fbe-9b43-cb48b013727f |
SCIP notification number (Finland) | 43d5ca8c-435e-4df9-b952-490a05978647 | SCIP notification number (France) | 3ac2e57a-f162-4e4a-a0f9-90d286d2a9b7 |
SCIP notification number (Germany) | c13735eb-626d-4f66-bddb-614eb8f44988 | SCIP notification number (Hungary) | 10ce5966-f83d-4d5f-9507-077b64580940 |
SCIP notification number (Italy) | a6425406-c804-47bb-9bac-eeea775ca85e | SCIP notification number (Netherlands) | 632ade62-88e9-4248-a77c-5c608e9ad760 |
SCIP notification number (Poland) | 51a8060d-e073-4310-8430-8a2666885727 | SCIP notification number (Romania) | 035cbedd-d758-41f2-ad55-70f4b8f277c2 |
SCIP notification number (Sweden) | 325ce1a1-14b2-42ef-ab39-6712796c1e97 |
Specifications may be subject to change without notice
