Product Model
758-940/004-000
Selling Points
- 1Utilizes EnOcean 868 MHz wireless technology for seamless communication.
- 2Offers a transmission range of up to 300 meters in open space and 30 meters within buildings.
- 3Features an integrated EnOcean PTM 200 Radio Transmitter antenna for efficient signal reception.
- 4Compatible with various frame programs and can be glued or screwed into position.
- 5Equipped with a maintenance-free energy generator for continuous operation.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note | Additional technical data can be found in the datasheets assigned as download. | Radio technology | EnOcean 868?MHz, RPS type?2 |
Transmission range | 300?m in open space, 30?m (typ.) within buildings | Antenna | Integrated EnOcean PTM 200 Radio Transmitter |
Width | 71?mm?/ 2.795?inches | Height | 14?mm?/ 0.551?inches |
Depth | 71?mm?/ 2.795?inches | Color | pure white |
Weight | 53.1g | Ambient temperature (operation) | -25 … +65 °C |
Relative humidity (without condensation) | 95% | eCl@ss 10.0 | 27-14-42-01 |
eCl@ss 9.0 | 27-14-42-01 | ETIM 9.0 | EC001358 |
ETIM 8.0 | EC001358 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 10?(1)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454271657 |
Customs tariff number | 8536509065 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
