Product Model
769-307
Selling Points
- 1Secure Enclosure: Provides a secure enclosure for rail-mounted components, protecting against environmental factors.
- 2Efficient Connections: Facilitates efficient electrical connections between terminal blocks, simplifying wiring.
- 3Durable Construction: Constructed with high-quality materials for long-lasting performance in various applications.
- 4Easy Installation: Easy to install, ensuring quick setup and minimal downtime.
- 5Versatile Compatibility: Compatible with a wide range of WAGO terminal blocks and connectors, enhancing system versatility.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1.1?mm?/ 0.043?inches | Height | 52.5?mm?/ 2.067?inches |
Depth | 24.1?mm?/ 0.949?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.036MJ | Weight | 1.2g |
Product Group | 18 (X-COM-System) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332529037 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
