Product Model
769-314
Selling Points
- 1High-Quality Construction: Made from durable gray polyamide 66 (PA 66) for long-lasting performance.
- 2Versatile Connectivity: Accommodates 8 feed-through poles and supports 16 wires with a nominal cross-section of 4mm².
- 3DIN-Rail Mounting: Designed for easy installation on DIN-rail 35 x 15 and 35 x 7.5.
- 4CAGE CLAMP Technology: Utilizes CAGE CLAMP spring connections for secure and reliable connections.
- 5Compliant with ROHS Standards: Meets ROHS compliance requirements for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1.1?mm?/ 0.043?inches | Height | 87.2?mm?/ 3.433?inches |
Depth | 32.3?mm?/ 1.272?inches | Note (material data) | Information on material specifications can be found here |
Color | orange | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.068MJ | Weight | 2.3g |
Product Group | 18 (X-COM-System) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4017332601658 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
