Product Model
770-526
Selling Points
- 1Secure 5-Pole Connection: Ensures reliable electrical connections with a 5-pole design.
- 2Durable Copper Construction: Built with copper (SE Cu) and special tin coating for long-lasting performance.
- 3Temperature-Resistant: Insulating parts can operate at temperatures up to 105 °C.
- 4Easy Installation: Utilizes Push-in CAGE CLAMP(R) spring pressure connection technology for quick and secure installation.
- 5RoHS Compliant: Meets environmental product compliance standards, ensuring eco-friendliness and safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 25.6 mm / 1.008 inches | Height | 5.45 mm / 0.215 inches |
Depth | 44.8 mm / 1.764 inches | Suitable | for socket and plug |
Note (material data) | Information on material specifications can be found here | Weight | 0.3g |
Material | Copper (SE Cu); special tin coating | Processing temperature | -5 … +40 °C |
Continuous operating temperature | -35 … +85 °C | Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C |
ETIM 9.0 | EC002863 | ETIM 8.0 | EC002863 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 50?pcs |
Packaging type | Box | Country of origin | DE |
GTIN | 4066966242829 | Customs tariff number | 85366990990 |
RoHS Compliance Status | Compliant,No Exemption | Number of poles | 5 |
Specifications may be subject to change without notice
