Product Model
788-166
Selling Points
- 1Designed for robust performance in industrial environments.
- 2Handles 20 VAC input voltage with a continuous current capacity of 6 A.
- 3Suitable for a wide range of industrial automation tasks.
- 4Includes a yellow LED status indicator and IP20 protection.
- 5Built to withstand mechanical stress with a mechanical life of 5 x 10^6 switching operations.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Dielectric strength (control/load circuit) (AC, 1?min) | 5?kVrms | Dielectric strength (open contact) (AC, 1?min) | 1?kVrms |
Protection type | IP40 | Width | 12.7?mm?/ 0.5?inches |
Height from the surface | 15.7?mm?/ 0.618?inches | Depth | 29?mm?/ 1.142?inches |
Mounting type | Pluggable module | Note (material data) | Information on material specifications can be found here |
Weight | 13.5g | Ambient temperature (operation at U<sub>N</sub>) | -40 … +85 °C |
Ambient temperature (storage) | -40 … +85 °C | Standards/specifications | EN 61810-1 |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-37-16-01 |
eCl@ss 9.0 | 27-37-16-01 | ETIM 9.0 | EC001437 |
ETIM 8.0 | EC001437 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 20?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4050821867821 |
Customs tariff number | 8536490080 | CAS-No. | 7439-92-1 |
REACH Candidate List Substance | Lead | RoHS Compliance Status | Compliant,No Exemption |
SCIP notification number (Austria) | 16096d40-862a-4080-8e57-03dee13f3fce | SCIP notification number (Belgium) | 28cd4897-4365-4fc4-be7f-161396e9444c |
SCIP notification number (Bulgaria) | 92ec6987-1918-46e2-ab8c-396f1b48a543 | SCIP notification number (Czech Republic) | 2479179b-3b45-451e-bd2b-761e4fb4b1e2 |
SCIP notification number (Denmark) | 58acb7be-cae4-49b0-a2a8-d4b1e3aa208e | SCIP notification number (Finland) | e5fc0b12-024f-483b-9d59-f7897c9ae461 |
SCIP notification number (France) | 9cb546f8-1a95-46af-818c-526138c5bbdb | SCIP notification number (Germany) | cf0c0be9-e526-4ac2-8ed0-7f7d102733c3 |
SCIP notification number (Hungary) | a2a4f7dd-3d79-4660-bf96-e54e1fa62a78 | SCIP notification number (Italy) | a194b18e-32a4-4cd2-a8f1-1b86b75ac233 |
SCIP notification number (Netherlands) | ef453ad3-3acd-4e79-b5e9-8c8995d62a43 | SCIP notification number (Poland) | 87467a93-31df-4b93-a3d3-fcc1dfc981cb |
SCIP notification number (Romania) | 2c17f364-cb62-4df0-9a2d-7287981f2716 | SCIP notification number (Sweden) | 80134039-1839-474a-a10f-4c9a1ed5f0fc |
Nominal input voltage U<sub>N</sub> | DC?110?V | Nominal input current at U<sub>N</sub> | 4?mA |
Number of changeover contacts | 1 | Contact material (relay) | AgNi 90/10 |
Limiting continuous current | 16?A | Inrush current (resistive) max. | (AC) 30?A?/ 4?s |
Switching Voltage, Max. | AC?250?V | Switching power (resistive) max. | AC?4000?VA;?DC (see load limit curve) |
Switching capacity | AC-15:?6?A?/ AC?250?V;?DC-13:?2?A?/ DC?24?V | Recommended minimum load | 12?V?/ 10?mA |
Pull-in time (typ.) | 8ms | Drop-out time (typ.) | 6ms |
Bounce time (typ.) | 6ms | Electrical life (NO; resistive load; 23?°C) | 30?x 103 switching operations |
Mechanical life | 30?x 10? switching operations | Switching frequency with/without load (max.) | 6?min-1/ 1200?min-1 |
Specifications may be subject to change without notice
