Product Model
793-5501/000-002
Selling Points
- 1Easy Installation: Snap-on type for quick and secure mounting.
- 2Customizable Labels: Use WAGO Configurator Smart Designer to label markers as needed.
- 3RoHS Compliant: Meets environmental regulations with halogen-free and UV-resistant materials.
- 4High-Quality Material: Yellow-colored, stretchable markers with smear resistance (EN 60998-1:2004).
- 5Versatile Compatibility: Suitable for terminal blocks 5-17.5mm wide, including 4-4.2mm and 5-12mm blocks.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Marking method | plotting | Marking | plain |
Delivery form | Marker card | Delivery form configuration | 10 strips with 10 markers per card |
Flammability class per UL94 | V2 | Marker/strip width | 5 … 5.2?mm |
Marker width | 5mm | Smear resistance | EN 60998-1:2004 |
Color | yellow | UV resistance | EN 60068-2-5:2010 Procedure B |
Halogen-free | Yes | Weight | 8.8g |
Fire load | 0.264MJ | eCl@ss 10.0 | 27-14-11-37 |
eCl@ss 9.0 | 27-14-11-37 | ETIM 9.0 | EC000761 |
ETIM 8.0 | EC000761 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 50?(5)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4045454001940 |
Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
