Product Model
831-1032
Selling Points
- 1High-quality, durable design for long-lasting use.
- 2Easy-to-use and install, reducing setup time.
- 3Excellent electrical conductivity and low resistance.
- 4Compact size for space-efficient installations.
- 5Compatible with a wide range of industrial applications.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 15.1?mm?/ 0.594?inches | Height | 11.2?mm?/ 0.441?inches |
Height from upper-edge of DIN-rail | 6.6?mm?/ 0.26?inches | Depth | 88.4?mm?/ 3.48?inches |
Mounting type | Panel mounting | Note (material data) | Information on material specifications can be found here |
Color | light gray | Material group | I |
Insulation material (main housing) | Polybutylene terephthalate (PBT) | Flammability class per UL94 | V0 |
Fire load | 0.232MJ | Weight | 6.4g |
Limit temperature range | -60 … +105?°C | Processing temperature | -35 … +60?°C |
ETIM 9.0 | EC002848 | ETIM 8.0 | EC002848 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 12?pcs |
Packaging type | Box | Country of origin | PL |
GTIN | 4066966112405 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
