Product Model
832-542
Selling Points
- 1Industry-leading reliability with robust design.
- 2Versatile connectivity options for various industrial settings.
- 3High current ratings for demanding applications.
- 4Easy installation and maintenance with secure connections.
- 5Durable materials for long-lasting performance in harsh environments.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 20.2?mm?/ 0.795?inches | Height | 8.94?mm?/ 0.352?inches |
Depth | 81.15?mm?/ 3.195?inches | Mounting type | Snap-in mounting |
Suitable | for standard male and female connectors | Locking of plug-in connection | Center locking lever |
Note (material data) | Information on material specifications can be found here | Color | orange |
Material group | I | Insulation material (main housing) | Polybutylene terephthalate (PBT) |
Flammability class per UL94 | V0 | Fire load | 0.101MJ |
Weight of insulation material | 3.35g | Weight | 3.4g |
Processing temperature | -35 … +60?°C | ETIM 9.0 | EC002848 |
ETIM 8.0 | EC002848 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 60?(10)?pcs | Packaging type | box |
Country of origin | DE | GTIN | 4055143961073 |
Customs tariff number | 3926909985 | RoHS Compliance Status | Compliant,No Exemption |
Number of poles | 2 |
Specifications may be subject to change without notice
