Product Model
857-165
Selling Points
- 128mm depth, 15mm height, and 5mm width for easy integration.
- 2Operates in -30°C to +80°C ambient temperature range.
- 3Rated for 0.1A continuous current output.
- 4≤1 kHz switching frequency and ≤100µs turn-on time.
- 5Easy installation with plug-in connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note | Optocouplers and solid state relays are designed for use in signal processing networks that are not supplied directly by the low-voltage power supply network. | Dielectric strength (control/load circuit) (AC, 1?min) | 3.75?kVrms |
Width | 5?mm?/ 0.197?inches | Height from the surface | 15?mm?/ 0.591?inches |
Depth | 28?mm?/ 1.102?inches | Mounting type | Pluggable module |
Note (material data) | Information on material specifications can be found here | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V0 | Weight | 3.2g |
Ambient temperature (operation at U<sub>N</sub>) | -30 … +80 °C | Ambient temperature (storage) | -40 … +100 °C |
Relative humidity | 5 … 95?% (no condensation permissible) | Operating altitude (max.) | 2000m |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-26-15-03 |
eCl@ss 9.0 | 27-26-15-03 | ETIM 9.0 | EC001504 |
ETIM 8.0 | EC001504 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 20?pcs | Packaging type | Box |
Country of origin | IT | GTIN | 4045454997663 |
Customs tariff number | 85365005000 | RoHS Compliance Status | Compliant,No Exemption |
Nominal input voltage U<sub>N</sub> | DC?60?V | Input voltage range (low level) | DC?0 … 10?V |
Input voltage range (high level) | DC?35 … 72?V | Nominal input current at U<sub>N</sub> | 3?mA |
Circuit type | 2-wire connection | Limiting continuous current | 0.1?A |
Nominal output voltage | DC?24?V | Output voltage range | DC 0 … 48?V |
Voltage drop | ≤ 1?VDC | Leakage current at rated voltage | ≤?1?μA |
Switching current (min.) | 50?μA | Turn-on time | ≤?100?μs |
Turn-off time | ≤?600?μs | Switching frequency | ≤?1?kHz |
Specifications may be subject to change without notice
