Product Model
859-397
Selling Points
- 1High-Performance Railway Relay: Designed for railway applications with robust features.
- 2Nominal Input Voltage 48 VDC: Compatible with standard DC power supplies.
- 31 Changeover Contact: Single-pole changeover contact configuration for precise control.
- 4Red Status Indicator: Easy visual indication of relay status with a red LED.
- 5DIN-35 Rail Mounting: Compact 6 mm width for easy DIN-35 rail mounting.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note | To protect the relay coils and contacts, inductive loads must be dampened with an effective protection circuit. | Rated voltage | 300V |
Rated surge voltage | 4kV | Overvoltage category | III |
Pollution degree | 2 | Dielectric strength (control/load circuit) (AC, 1?min) | 4?kVrms |
Dielectric strength (open contact) (AC, 1?min) | 1?kVrms | Insulation type (control/load circuit) | Reinforced insulation (safe isolation) |
Insulation type (adjacent devices) | Reinforced insulation (safe isolation) | Protection type | IP20; in connected state or when using 859-525 end plate |
Connection technology | CAGE CLAMP? | Solid conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG |
Fine-stranded conductor | 0.08 … 2.5?mm2?/ 28 … 14?AWG | Fine-stranded conductor; with insulated ferrule | 0.08 … 1.5?mm2?/ 28 … 16?AWG |
Strip length | 5 … 6?mm?/ 0.2 … 0.24?inches | Width | 6?mm?/ 0.236?inches |
Height | 91?mm?/ 3.583?inches | Depth from upper-edge of DIN-rail | 56?mm?/ 2.205?inches |
Mounting type | DIN-35 rail | Mounting position | Horizontal (standing/lying); vertical |
Note (material data) | Information on material specifications can be found here | Insulation material (main housing) | Polyamide (PA66) |
Material group | I | Flammability class per UL94 | V0 |
Fire load | 0.338MJ | Weight | 23.2g |
Ambient temperature (operation at U<sub>N</sub>) | -40 … +70 °C | Ambient temperature (storage) | -40 … +70 °C |
Processing temperature | -25 … +50?°C | Temperature range of connection cable | ≥ (Tambient+ 20 K) |
Relative humidity | 5 … 95?% (no condensation permissible) | Operating altitude (max.) | 2000m |
Standards/specifications | EN 61010-2-201 | Product Group | 6 (INTERFACE ELECTRONIC) |
eCl@ss 10.0 | 27-37-16-01 | eCl@ss 9.0 | 27-37-16-01 |
ETIM 9.0 | EC001437 | ETIM 8.0 | EC001437 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 10?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4055143604468 | Customs tariff number | 8536490050 |
CAS-No. | 7439-92-1 | REACH Candidate List Substance | 2,2',6,6'-tetrabromo-4,4'-isopropylidenediphenol |
RoHS Compliance Status | Compliant,With Exemption | RoHS Exemption | 7(a) |
SCIP notification number (Austria) | 41943199-025a-489d-8b9a-531bf841f223 | SCIP notification number (Belgium) | 7965d6b5-7a48-49f8-b116-2a54bcbfff9b |
SCIP notification number (Bulgaria) | b3d2c2f2-c897-4608-b139-b56d742a32c1 | SCIP notification number (Czech Republic) | 5292599a-7b0e-424d-a5f3-7caafc35e33f |
SCIP notification number (Denmark) | 9fcf8dd6-a7be-49d2-8214-f55ba1cfec1a | SCIP notification number (Finland) | fd91d615-55cf-47df-83fb-3e709ca1c3c2 |
SCIP notification number (France) | 99ba37e7-3d9e-4ea9-8f67-0443eff3ad76 | SCIP notification number (Germany) | ff17c057-6d12-4e36-ba06-a915200f6f08 |
SCIP notification number (Hungary) | 514207e3-c253-4a2c-bca9-cf4b0f312437 | SCIP notification number (Italy) | e4d86041-5e07-477d-90a1-6361f416baf4 |
SCIP notification number (Netherlands) | c8bc4bfb-293d-4753-993e-6135be8383c1 | SCIP notification number (Poland) | 0719f484-78e1-4549-a34f-4f54d0f83ca6 |
SCIP notification number (Romania) | 08e28d55-559b-431c-be63-41089606ebc4 | SCIP notification number (Sweden) | e60023e7-1765-4c55-8e22-e833f36d16d7 |
Nominal input voltage U<sub>N</sub> | DC?48?V | Input voltage range | ±40?% |
Nominal input current at U<sub>N</sub> | 8?mA | Number of changeover contacts | 1 |
Contact material (relay) | AgSnO2 | Limiting continuous current | 5?A |
Switching Voltage, Max. | AC?250?V | Switching power (resistive) max. | AC?1250?VA;?DC (see load limit curve) |
Switching capacity | AC-15:?3?A?/ AC?250?V;?DC-13:?2?A?/ DC?24?V | Recommended minimum load | 10?V?/ 10?mA;?24?V?/ 1?mA |
Pull-in time (typ.) | 15ms | Drop-out time (typ.) | 25ms |
Bounce time (typ.) | 3.5ms | Electrical life (NO; resistive load; 23?°C) | 50?x 103 switching operations |
Mechanical life | 5?x 10? switching operations | Switching frequency with/without load (max.) | 6?min-1/ 180?min-1 |
Status indicator | Red LED |
Specifications may be subject to change without notice
