Product Model
859-525
Selling Points
- 1Compact design for DIN rail mounting, saving up to 70% space.
- 2Easy commoning with jumper slots on both input and output sides.
- 3Suitable for solid, stranded, and fine-stranded conductors with ferrules.
- 4Rated voltage of 250V and current rating of 5A.
- 5RoHS compliant with lead-free construction.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 1?mm?/ 0.039?inches | Depth | 90.4?mm?/ 3.559?inches |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.142MJ | Weight | 4.9g |
Product Group | 6 (INTERFACE ELECTRONIC) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 100?(25)?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4017332611695 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
