Product Model
870-408
Selling Points
- 1Insulated push-in jumper bar with 8 positions.
- 2Ideal for rail-mounted terminal blocks.
- 3Rated current of 18A for high-current applications.
- 4Light gray color for easy identification.
- 5Compliant with RoHS standards for environmental safety.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 39?mm?/ 1.535?inches | Height | 2.5?mm?/ 0.098?inches |
Jumper assignment | 1-2-3-4-5-6-7-8 | Note (material data) | Information on material specifications can be found here |
Color | light gray | Fire load | 0.043MJ |
Weight | 3.5g | Product Group | 16 (Rail Mounted Terminal Blocks with CCC) |
eCl@ss 10.0 | 27-14-11-40 | eCl@ss 9.0 | 27-14-11-40 |
ETIM 9.0 | EC000489 | ETIM 8.0 | EC000489 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 25?(25)?pcs |
Packaging type | Bag | Country of origin | DE |
GTIN | 4066966274493 | Customs tariff number | 8536698000 |
RoHS Compliance Status | Compliant,No Exemption | Rated current | 18A |
Rated current (Ex e II) | 13.5A |
Specifications may be subject to change without notice
