Product Model
883-2443
Selling Points
- 1High Voltage Rating: 1000V nominal voltage for reliable performance.
- 2High Current Capacity: 380A rated current for efficient power transfer.
- 3Insulated Design: 3-way insulated for added safety and durability.
- 4Compact Size: 103.1 mm / 4.059 inches width for easy integration.
- 5Durable Material: Made from high-quality polyamide (PA66) for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 103.1?mm?/ 4.059?inches | Note (material data) | Information on material specifications can be found here |
Color | yellow | Insulation material (main housing) | Polyamide (PA66) |
Flammability class per UL94 | V2 | Weight | 317.8g |
ETIM 9.0 | EC000489 | ETIM 8.0 | EC000489 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 5?pcs |
Packaging type | bag | Country of origin | DE |
GTIN | 4055143940726 | Customs tariff number | 8536698000 |
RoHS Compliance Status | Compliant,No Exemption | Rated voltage (III / 3) | 1000V |
Rated current | 380A |
Specifications may be subject to change without notice
