Product Model
885-546
Selling Points
- 1Built with durable materials for long-lasting performance in harsh industrial environments.
- 2Simple and quick setup with minimal technical expertise required.
- 3Supports various communication protocols for seamless integration with existing systems.
- 4Features robust security measures to protect against unauthorized access and data breaches.
- 5Ideal for both small-scale and large-scale industrial automation projects, offering flexibility and adaptability.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 2?mm?/ 0.079?inches | Height | 102.3?mm?/ 4.028?inches |
Depth | 58.8?mm?/ 2.315?inches | Note (material data) | Information on material specifications can be found here |
Color | gray | Material group | I |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.294MJ | Weight | 9.8g |
Product Group | 1 (Rail Mounted Terminal Blocks) | eCl@ss 10.0 | 27-14-11-33 |
eCl@ss 9.0 | 27-14-11-33 | ETIM 9.0 | EC000886 |
ETIM 8.0 | EC000886 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 25?pcs | Packaging type | box |
Country of origin | CN | GTIN | 4050821092056 |
Customs tariff number | 8538906000 | RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
