Product Model
890-643
Selling Points
- 1High-Quality Material: Made from durable polyamide (PA66) for reliable performance.
- 2Easy Integration: Compatible with a range of systems, ensuring seamless integration.
- 3Temperature Resistance: Operates within -35°C to +85°C, suitable for various environments.
- 4Flammability Class V0: Meets UL94 standards for fire safety, ensuring secure connections.
- 5Snap-in Flange Mounting: Easy to install with a snap-in flange design for quick setup.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Mounting type | Snap-in flange | Suitable | for cutout |
Note (material data) | Information on material specifications can be found here | Color | black |
Insulation material (main housing) | Polyamide (PA66) | Flammability class per UL94 | V0 |
Fire load | 0.041MJ | Weight | 1.4g |
Processing temperature | -5 … +40?°C | Continuous operating temperature | -35 … +85?°C |
Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C | Product Group | 20 (Winsta) |
eCl@ss 10.0 | 27-44-06-92 | eCl@ss 9.0 | 27-44-06-92 |
ETIM 9.0 | EC002863 | ETIM 8.0 | EC002863 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 100?pcs |
Packaging type | box | Country of origin | DE |
GTIN | 4045454526498 | Customs tariff number | 3926909985 |
RoHS Compliance Status | Compliant,No Exemption | Number of poles | 3 |
Specifications may be subject to change without notice
