Product Model
897-121
Selling Points
- 12 x 1.5 mm² PVC insulation ensures reliable performance.
- 2Designed for 50 V applications, ideal for various industrial uses.
- 3Light gray color and robust material for long-lasting service.
- 4Operating temperature range from -25°C to +70°C, suitable for diverse environments.
- 5Convenient installation and commissioning process for seamless integration.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 10.9?mm?/ 0.43?inches | Height | 6.1?mm?/ 0.24?inches |
Variable coding | No | Mismating protection | No |
Note (material data) | Information on material specifications can be found here | Color | light gray |
Fire class per EN 50575 | Eca | Fire load | 1.728MJ |
Silicon-free | Yes | Sheath material | PVC |
Rubber cable | No | Weight | 90g |
Copper weight of the pipe | 0.029kg/m | Processing temperature | 5 … 40?°C |
Continuous operating temperature | -25 … +70?°C | Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C |
Product Group | 20 (Winsta) | eCl@ss 10.0 | 27-06-01-06 |
eCl@ss 9.0 | 27-06-20-02 | ETIM 9.0 | EC003250 |
ETIM 8.0 | EC003250 | ECCN | NO US CLASSIFICATION |
PU (SPU) | 1?pcs | Packaging type | box |
Country of origin | CH | GTIN | 4045454267315 |
Customs tariff number | 8544429090 | RoHS Compliance Status | Compliant,No Exemption |
Legend (ratings) | (III / 3) ? Overvoltage category III / Pollution degree 3 | Number of poles | 2 |
Wire cross-section | 1.5mm2 |
Specifications may be subject to change without notice
