Product Model
897-232
Selling Points
- 1Halogen-Free Design: Ensures safety in hazardous locations.
- 2Compact and Reliable: Easy to use with WAGO's compact 221 Series Splicing Connector.
- 3Versatile Applications: Suitable for intercom system wiring, electrical ovens, and more.
- 4High Voltage Rating: 0.6/1 kV for reliable connections in various environments.
- 5Durable Construction: Made with high-quality materials for long-lasting performance.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Width | 16.9?mm?/ 0.66?inches | Height | 6.5?mm?/ 0.26?inches |
Variable coding | No | Mismating protection | No |
Note (material data) | Information on material specifications can be found here | Color | light gray |
Insulation material (main housing) | Polyamide 66 (PA 66) | Fire class per EN 50575 | B2ca |
Fire load | 2.085MJ | Halogen-free | Yes |
Silicon-free | Yes | Rubber cable | No |
Weight | 100g | Copper weight of the pipe | 0.072kg/m |
Processing temperature | 5 … 40?°C | Continuous operating temperature | -25 … +90?°C |
Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C | Product Group | 20 (Winsta) |
eCl@ss 10.0 | 27-06-01-06 | eCl@ss 9.0 | 27-06-20-02 |
ETIM 9.0 | EC003250 | ETIM 8.0 | EC003250 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 1?pcs |
Packaging type | box | Country of origin | CH |
GTIN | 4045454004187 | Customs tariff number | 8544429090 |
RoHS Compliance Status | Compliant,No Exemption | Rated voltage | 0.6 / 1?kV |
Legend (ratings) | (III / 3) ? Overvoltage category III / Pollution degree 3 | Number of poles | 3 |
Wire cross-section | 2.5mm2 |
Specifications may be subject to change without notice
