Product Model
897-900
Selling Points
- 1Flexible cable management with snap-in device connection.
- 2High-voltage rated up to 250V/4kV.
- 3AWG 22 - 16 wire range for versatile use.
- 4Easy installation with no cutting required.
- 5Strain relief housing for durable connections.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Note (material data) | Information on material specifications can be found here | Color | black |
Insulation material (main housing) | Polyamide 66 (PA 66) | Weight | 31.5g |
Processing temperature | -5 … +40?°C | Continuous operating temperature | -35 … +85?°C |
Note on continuous operating temperature | Insulating parts for temperatures ≤ 105 °C | Product Group | 20 (Winsta) |
eCl@ss 10.0 | 27-44-06-92 | eCl@ss 9.0 | 27-14-44-27 |
ETIM 9.0 | EC000128 | ETIM 8.0 | EC000128 |
ECCN | NO US CLASSIFICATION | PU (SPU) | 10?pcs |
Packaging type | box | Country of origin | CH |
GTIN | 4045454004248 | Customs tariff number | 3919102055 |
RoHS Compliance Status | Compliant,No Exemption |
Specifications may be subject to change without notice
