Product Model
3VA2325-5JQ32-0AA0
Selling Points
- 1High breaking capacity of 55 kA @ 415 V for efficient short-circuit protection.
- 2Integrated ETU560 for enhanced line protection and selective tripping.
- 3Overload protection up to 250 A for safe operation in various applications.
- 4Compact design with plug-in technology for easy installation and maintenance.
- 5Advanced communication capabilities for seamless integration with fieldbus systems.
Technical Specifications
Detailed engineering parameters based on manufacturer documentation
| Parameter | Value | Parameter | Value |
|---|---|---|---|
Rated Service Breaking Capacity Ics(kA):@400V or 415V | 55 | Rated Voltage(V): | 690 |
Number of Poles: | 3P | Description | 3VA2M400 R250 ETU560 F/3P; 3VA2_400 dimensions; Rated current 250A; Interrupting rating M:55kA; Trip unit ETU560; |
Mounting Method: | F: Fixed | Trip Unit: (If required is not in the list, reset and select trip unit first) | ETU560 [Electronic LSIG + LCD] |
Rated Ultimate Breaking Capacity Icu(kA):@400V or 415V | 55 | Interrupting Rating: | M:55kA |
Rated Current In(A): | 250 | Specifications: | 400 [250-400A] |
Lifecycle | Delivery Release (PM300) | Country of Origin | China |
ECCN | 9N9999 | AL | N |
Model Number | 3VA2325-5JQ32-0AA0 |
Specifications may be subject to change without notice
