Siemens

Siemens 7KN Series Cabinet Manager PRO

SENTRON PAC1020 96X96 mm Power Monitoring Device, a panel-mounted device used for measuring electrical energy, with Modbus RTU protocol and graphical display. Nominal maximum values of UE: 400/230V, 45-65Hz. Nominal values of IE: X/5A AC. Auxiliary power supply: 85V - 276V AC. Connection via screw terminal connectors.

Siemens 7KN Series Cabinet Manager

SENTRON PAC3220 LCD 96X96 mm Power Monitoring Device, a panel-mounted equipment designed for measuring electrical energy. Protocol: Modbus TCP with graphical display. Nominal UE: 690/400V, 45-65Hz. Nominal IE: X/1A or X/5A AC. Auxiliary power supply: 100...250 V ±10% AC/DC. Terminal connection via screw-type terminals.

Expansion module 4DI/2DO, pluggable, for 7KM PAC3200/4200

Expansion module I (N), I (Diff), analog N lines, differential current measurement, 2 analog input channels, pluggable, for 7KM PAC3200/4200

Siemens 7KN series IoT Data Platform (POC3000)

Switched Ethernet PROFINET expansion module, pluggable, for 7KM PAC3200/4200/3VA COM100/800

SENTRON, meter, 7KM PAC4200, LCD, L-L: 500V, L-N: 289V, 5A, three-phase, Modbus TCP, optional Modbus RTU/PROFINET/PROFIBUS/digital input/digital output, apparent/effective/reactive electric energy/cos phi, harmonic: 2-64, THD, accuracy class 0.2 according to IEC61557-12 or accuracy class 0.2S according to IEC62053-22, ultra-low voltage power supply, DC, screw terminal connection.

SENTRON, Instrument, 7KM PAC4200 and recessed top rail adapter, LCD, L-L: 500 V, L-N: 289 V, 5 A, three-phase, Modbus TCP, optional Modbus RTU/PROFINET/PROFIBUS/DI/DO, apparent/effective/reactive energy/cos phi, harmonics: 3rd to 31st, THD, accuracy class 0.2 according to IEC61557-12 or accuracy class 0.2S according to IEC62053-22, low voltage power supply, DC, bolt-type terminal connection.

Compact bracket for 7KM3133-0BA00-3AA0, 7KM2111-1BA00-3AA0, 7KM2112-0BA00-3AA0, 7KM4211-1BA00-3AA0, 7KM4212-0BA00-3AA0

SENTRON, Meter, 7KM PAC4200, LCD, L-L: 690 V, L-N: 400 V, 5 A, three-phase, Modbus TCP, optional Modbus RTU/PROFINET/PROFIBUS/digital input/digital output, apparent/effective/reactive electric energy/cos phi, harmonics: 2-64, THD, accuracy class 0.2 according to IEC61557-12 or accuracy class 0.2S according to IEC62053-22, power supply with wide voltage range, AC/DC, bolt terminal connection.

SENTRON, Meter, 7KM PAC3100, LCD, L-L: 480V, L-N: 277V, 3-phase, Modbus RTU, Active/Reactive Energy, Class 1 according to IEC 61557-12 or IEC 62053-21, wide voltage range power supply, AC/DC, bolt-on terminal connection.

Expansion module RS485, pluggable, for 7KM PAC3200 / 4200 / 3VA COM100 / 800

Expansion module PROFIBUS DP, pluggable, for 7KM PAC3200 / 3220 / 4200 / 3VA COM100 / 800

Siemens 7KN Series Cabinet Manager (170-point Expansion Package)

SENTRON PAC3120 LCD 96X96 mm Power Monitoring Device, Built-in Panel Mount Equipment for Measuring Electrical Energy. Protocol: Modbus RTU with Graphic Display. UE Rating: 690/400V, 45-65Hz. IE Rating: X/1A or X/5A AC. Auxiliary Power Supply: 100...250 V AC/DC ±10%. Terminal Connection: Screw Terminal.

Siemens 7KN Series Cabinet Service Unit

Switched Ethernet Ethernet PROFINET V3, pluggable, for 7KM PAC3200/3220/4200/3VA COM100/800
